Eclisse Double Fire Rated Pocket Door System

(0 Reviews)  Review this item

Please READ - Certified for use with the following 44mm FD30 door panels (not supplied) under field of application report PAR /10057/01 Revision E

Compatible and certified accessories:

Refer to the report here for information on which non-essential hardware (i.e. push plates, kick plates, handles) has been approved for use.

*Please check first with your Building Inspector prior to ordering to determine whether or not your particular application will require a self-closer.

** Except for Jeldwen Paint Grade Premium door panel and the Vicaima options. Please see field of application report for details. See also Letter of Comfort re handles

PACKAGES INCLUDES:

  • Eclisse pocket double door frame including track and runners, bolts into 70mm stud work creating a 120mm wall finish when used with two layers 12.5mm fireboards each side (fireboards by others).
  • Complete with special designed jamb with integrated architrave made from a high-density slow burning hardwood, pre-treated with intumescent primer.
  • Full set of FD30 Intumescent strips (white as default) brown available on request



Doors, plasterboard NOT supplied.

Need help in choosing the RIGHT SIZE? Click here

Why choose an Eclisse Pocket door kit from Pocketdoorshop.co.uk?

Download - Data Sheet | Fire Certificate - Report | Frame Installation |

Sales BannerOrder before 2pm (weekday) for a next working day delivery.

FRAME SIZE DOOR SIZE
MAX PASSAGE SIZE (PW X PH) OVERALL DIMS OPENING W X H FINISHED WALL DW (WIDTH) DH (HEIGHT) PRICE 1+ (ex vat) PRICE 3+ (ex vat) BUY
1180 x 2020 2494 x 2120 120 626 2040 £779.00 £740.00
1380 x 2020 2894 x 2120 120 726 2040 £779.00 £740.00
1580 x 2020 3294 x 2120 120 826 2040 £779.00 £740.00
1780 x 2020 3694 x 2120 120 926 2040 £779.00 £740.00
1150 x 1960 2464 x 2061 120 610 1981 £779.00 £740.00
1302 x 1960 2816 x 2061 120 686 1981 £779.00 £740.00
1454 x 1960 3168 x 2061 120 762 1981 £779.00 £740.00
1606 x 1960 3320 x 2061 120 838 1981 £779.00 £740.00

Double Fire Rated Dimensions

Additional Product Features:

  • Complete with special designed jamb with integrated architrave made from a high-density slow burning hardwood, pre-treated with intumescent primer.
  • Maintenance-free track and runners.
  • Fully adjustable front and rear track doorstops.
  • Anti-warp door profile
  • Self-centering floor guide
  • 15 year guarantee on the complete Eclisse steel pocket system and runners
  • When fitting flush pull handles we recommend the stop be regulated so the door protrudes from the pocket to avoid risk to fingers. Should the door be adjusted to enter the pocket completely we do not accept any liability.



DescriptionSizeFormatGet File
Jeldwen Fire Door Range285550.pdfDOWNLOAD
Vicaima Fire Door Range160746.pdfDOWNLOAD
XL Joinery Fire Door Range1841794.pdfDOWNLOAD
Letter of Comfort - Handles116195.pdfDOWNLOAD
Field of Application Report REV E - Eclisse Fire Rated Pocket Door Kits702258.pdfDOWNLOAD
Installation Guide - Eclisse Classic Unico Double FD30 1561389.pdfDOWNLOAD
Installation Guide - Double Classic Fire Jamb 877568.pdfDOWNLOAD
Installation Guide - Self Closing Unit1054054.pdfDOWNLOAD
Data Sheet - Eclisse Double Fire Rated Pocket Door Kit 430972.pdfDOWNLOAD
